Alctron MP100V2 Tube/Trans Microphone Preamp
Alctron MP100V2 Tube/Trans Microphone Preamp

Alctron MP100V2 Tube/Trans Microphone Preamp

Regular price $529.00 $439.00 Sale



MP100V2

Tube mic pre-amplifiers




Tube mic amplifier

Its shell adopts dust-free spraying processing

Provides extra shielding against stray magnetic and RF

Features tube/fet and MTR button

MP100V2 is a tube microphone amplifier. its creative electronic circuit combines tube and FET functional to add the tonal versatility and catches detail sound quality. Via TRANS & TUBE knob to adjust the ratio between trans and tube which makes MP100V2 suitable for various mics. The high quality 12AX7B tube amplifies sound in a premium way which makes the output sound more clear and natural. Various knobs, alum and steel material make MP100V2 fashionable and durable.

1、Tube mic amplifier

2、Its shell adopts dust-free spraying processing

3、Provides extra shielding against stray magnetic and RF

4、Features tube/fet and MTR button

5、Adopts 12AX7B tube DI circuit design to premium performance

6、Front panel mic gain knob increases gain and makes sound full and smooth

7、Features 48V phantom power

* Type: tube microphone preamp
* Input: XLR and 1/4’’ jack
* Output: XLR
* Tube complement: 12a x 7
* Pad: -15dB
* Max power consumption: 160mA @120V AC, 20W
* Power requirements: 100-240V AC
* Mic input impedance: 2K ohm
* Line input impedance: 10K ohm
* Hi-Z input impedance: 2.2M ohm
* Internal output impedance: 600 ohm
* Gain range: 70dBu
* Mic gain range:  10-60dBu
* Line gain range: -10-40dBu
* Hi-Z gain range: -10-40dBu
* Mic frequency response: 20hz-20khz
* Line frequency response: 20hz-20khz
* Hi-Z frequency response: 20hz-20khz
* Min THD + noise @+4dBu: 0.1% tube 0.005%
